6 A SP MCB 6kA B Curve

  • Thermo-magnetic, current limiting type
  • Available in a range of current ratings
  • Operating dolly may be locked in either the ON or OFF position
  • The contacts themselves are manufactured from carefully chosen materials
  • Low electrical resistance and low propensity to weld under fault conditions
  • Busbar Connectivity- Thickness 3mm Max
  • Calibration Temperatre 30°C
  • IP20

Additional information

Height

87 mm

Width

17.7 mm

Depth

66.8 mm

Weight

0.14 Kg

Current Rating

6A

Compliance

BS EN 60898

Guarantee

25 Years

Incoming Terminal Capacity

25 mm2

Material

Urea case

Mounting

Din Rail

Number of Modules

1

Number of Poles

Single Pole

Outgoing Terminal Capacity

25 mm2

Packaging Types

Each

Short Circuit rating

6 kA

Tripping Characteristics

B Curve

Voltage Rating

230 V;400 V

UNSPSC

39121603
